BRIGHT104
TECHNICAL DETAILS
-High efficiency: Efficiency up to 130Lm/w at Ra90,160Lm/w at Ra80.
-High brightness: 2000-6000lm/m.
-Double ended power input: Both ends are equipped with input wires. After the light strip is cut, it can be used directly without the need for additional welding wires.
-Double layer FPC: Balancing the voltage dropping, heat dissipation and flexibility.
PRODUCT DESCRIPTION
| Model | Input | LED/M | M/Reel | LED type | CRI | IP rating | Power | Lumen/M | CCT |
|---|---|---|---|---|---|---|---|---|---|
| BRIGHT104 | DC24V | 240pcs/M | 5M/Reel* | SMD | >90 | IP20/IP65 | 35W/M / 40W/M | 4410 lm/M@3000K 5048 lm/M@3000K |
2700K/3000K/4000K/5000K/6500K |
COMPATIBILITY:
ON/OFFTriac0/1-10VDALIPWM
DIMENSIONS:
